FAG B7209-E-T-P4S-K5-UL

FAG B7209-E-T-P4S-K5-UL
FAG B7209-E-T-P4S-K5-UL rulman resim 1
FAG B7209-E-T-P4S-K5-UL rulman resim 2
FAG B7209-E-T-P4S-K5-UL rulman resim 3
Price: 250.43 $
Specifications
Brand FAG
Item Number B7209-E-T-P4S-K5-UL FAG
Manufacturer Part Number 0384361080000
EAN 4012801462242
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.4 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision K5 - P4S + K5
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 19
Basic static load rating, radial (C 0r) 16900
Limiting speed for grease lubrication (n G Grease) 15000
Limiting speed for oil lubrication (n G Oil) 24000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL Single Bearing, Universal, Light Preload
