FAG B7208C-T-P4S-UL

FAG B7208C-T-P4S-UL
FAG B7208C-T-P4S-UL rulman resim 1
FAG B7208C-T-P4S-UL rulman resim 2
FAG B7208C-T-P4S-UL rulman resim 3
FAG B7208C-T-P4S-UL rulman resim 4
Price: 202.88 $
Specifications
Brand FAG
Item Number B7208C.T.P4S.UL FAG
Also known as 7208CDGA/P4A
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 80
Width (B) MM 18
Inner (d) Inch 1.5748
Outer (D) Inch 3.1496
Width (B) Inch 0.7087
Weight (kg) 0.38 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
