FAG B7208-E-2RSD-T-P4S-UM

FAG B7208-E-2RSD-T-P4S-UM
FAG B7208-E-2RSD-T-P4S-UM rulman resim 1
FAG B7208-E-2RSD-T-P4S-UM rulman resim 2
FAG B7208-E-2RSD-T-P4S-UM rulman resim 3
FAG B7208-E-2RSD-T-P4S-UM rulman resim 4
Price: 262.94 $
Specifications
Brand FAG
Item Number B7208-E-2RSD-T-P4S-UM FAG
Manufacturer Part Number 0388012640000
EAN 4026677903525
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 80
Width (B) MM 18
Inner (d) Inch 1.5748
Outer (D) Inch 3.1496
Width (B) Inch 0.7087
Weight (kg) 0.38 kg
Product Properties
Seal 2RU - Two Seals / Non Contact Type
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 18
Basic static load rating, radial (C 0r) 15400
Limiting speed for grease lubrication (n G Grease) 17000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
2RSD Lip Seals On Both Sides, Non-Contact
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
