FAG B7204-E-T-P4S-UM

FAG B7204-E-T-P4S-UM
FAG B7204-E-T-P4S-UM rulman resim 1
FAG B7204-E-T-P4S-UM rulman resim 2
FAG B7204-E-T-P4S-UM rulman resim 3
Price: 117.47 $
Specifications
Brand FAG
Item Number B7204-E-T-P4S-UM FAG
Manufacturer Part Number 0730064830000
Also known as 7204ACDGB/P4A
EAN 4047643339858
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 47
Width (B) MM 14
Inner (d) Inch 0.7874
Outer (D) Inch 1.8504
Width (B) Inch 0.5512
Weight (kg) 0.11 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 14
Radial Static Load Rating C0r (N) 7700
Radial Dynamic Load Rating Cr (N) 16500
Basic static load rating, radial (C 0r) "7700.0000"
Limiting speed for grease lubrication (n G Grease) 30000
Limiting speed for oil lubrication (n G Oil) 45000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B72..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
