FAG B7204-E-2RSD-T-P4S-DUL

FAG B7204-E-2RSD-T-P4S-DUL
FAG B7204-E-2RSD-T-P4S-DUL rulman resim 1
FAG B7204-E-2RSD-T-P4S-DUL rulman resim 2
FAG B7204-E-2RSD-T-P4S-DUL rulman resim 3
Price: 345.35 $
Specifications
Brand FAG
Item Number B7204-E-2RSD-T-P4S-DUL FAG
Manufacturer Part Number 0727348170000
EAN 4012802766134
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 47
Width (B) MM 14
Inner (d) Inch 0.7874
Outer (D) Inch 1.8504
Width (B) Inch 0.5512
Weight (kg) 0.11 kg
Product Properties
Seal 2RU - Two Seals / Non Contact Type
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 14
Basic static load rating, radial (C 0r) 7700
Limiting speed for grease lubrication (n G Grease) 30000
Suffix description
E 25° Contact Angle
2RSD Lip Seals On Both Sides, Non-Contact
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DUL Set Of 2 Universal Bearings, Light Preload
