FAG B71912-E-T-P4S-K5-UL Image 2
Visual product photo and picture of the product.
Price: 262.94 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
85 |
| Width (B) MM |
13 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
3.3465 |
| Width (B) Inch |
0.5118 |
| Weight (kg) |
0.2 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
K5 - P4S + K5 |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
13 |
| Radial Static Load Rating C0r (N) |
15200 |
| Radial Dynamic Load Rating Cr (N) |
23400 |
| Basic static load rating, radial (C 0r) |
"15200.0000" |
| Limiting speed for grease lubrication (n G Grease) |
14000 |
| Limiting speed for oil lubrication (n G Oil) |
22000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Spindle bearing B719..-E-T-P4S, with steel balls |
Suffix description
| E |
25° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 |
Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL |
Single Bearing, Universal, Light Preload |
