FAG B7024-C-T-P4S-K5-UL Image 3

Visual product photo and picture of the product.

FAG B7024-C-T-P4S-K5-UL bearing image 3
FAG B7024-C-T-P4S-K5-UL bearing image 1
FAG B7024-C-T-P4S-K5-UL bearing image 2
FAG B7024-C-T-P4S-K5-UL bearing image 3
FAG B7024-C-T-P4S-K5-UL bearing image 4
Price: 760.94 $
Specifications
Brand FAG
Item Number B7024-C-T-P4S-K5-UL FAG
Manufacturer Part Number 0384344580000
EAN 4012801452878
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Width (B) MM 28
Width (B) Inch 1.1024
Weight (kg) 2.07 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision K5 - P4S + K5
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Medias description Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL Single Bearing, Universal, Light Preload
