FAG B7017-C-2RSD-T-P4S-K5-UL Image 3
Visual product photo and picture of the product.
Price: 573.86 $
Specifications
Weight and Dimensions
| Inner (d) MM |
85 |
| Outer (D) MM |
130 |
| Width (B) MM |
22 |
| Inner (d) Inch |
3.3465 |
| Outer (D) Inch |
5.1181 |
| Width (B) Inch |
0.8661 |
| Weight (kg) |
0.88 kg
|
Product Properties
| Seal |
2RU - Two Seals / Non Contact Type |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
K5 - P4S + K5 |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
22 |
| Basic static load rating, radial (C 0r) |
43500 |
| Limiting speed for grease lubrication (n G Grease) |
11000 |
Suffix description
| C |
15° Or 17° Contact Angle |
| 2RSD |
Lip Seals On Both Sides, Non-Contact |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C. P4S |
| K5 |
Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL |
Single Bearing, Universal, Light Preload |
