FAG B7013-E-2RSD-T-P4S-K5-UL Image 4
Visual product photo and picture of the product.
Price: 389.51 $
Specifications
Weight and Dimensions
| Inner (d) MM |
65 |
| Outer (D) MM |
100 |
| Width (B) MM |
18 |
| Inner (d) Inch |
2.5591 |
| Outer (D) Inch |
3.937 |
| Width (B) Inch |
0.7087 |
| Weight (kg) |
0.42 kg
|
Product Properties
| Seal |
2RU - Two Seals / Non Contact Type |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
K5 - P4S + K5 |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
18 |
| Basic static load rating, radial (C 0r) |
24100 |
| Limiting speed for grease lubrication (n G Grease) |
13000 |
Suffix description
| E |
25° Contact Angle |
| 2RSD |
Lip Seals On Both Sides, Non-Contact |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S.K5 |
Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL |
Single Bearing, Universal, Light Preload |
| L055 |
Lubrication |
