FAG B7012-C-2RSD-T-P4S-UL Image 3
Visual product photo and picture of the product.
Price: 328.50 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
95 |
| Width (B) MM |
18 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
3.7402 |
| Width (B) Inch |
0.7087 |
| Weight (kg) |
0.4 kg
|
Product Properties
| Seal |
2RU - Two Seals / Non Contact Type |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
18 |
| Radial Static Load Rating C0r (N) |
23800 |
| Radial Dynamic Load Rating Cr (N) |
40000 |
| Basic static load rating, radial (C 0r) |
"23800.0000" |
| Limiting speed for grease lubrication (n G Grease) |
15000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Spindle bearings B70..-C-2RSD, adjusted, in pairs or sets, contact angle a = 15°, lip seals on both sides, non-contact, restricted tolerances |
Suffix description
| C |
15° Or 17° Contact Angle |
| 2RSD |
Lip Seals On Both Sides, Non-Contact |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL |
Single Bearing, Universal, Light Preload |
