FAG B7010-C-T-P4S-DUL Image 2
Visual product photo and picture of the product.
Price: 405.02 $
Specifications
Weight and Dimensions
| Inner (d) MM |
50 |
| Outer (D) MM |
80 |
| Width (B) MM |
32 |
| Inner (d) Inch |
1.9685 |
| Outer (D) Inch |
3.1496 |
| Width (B) Inch |
1.2598 |
| Weight (kg) |
0.52 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
DL - 2 Univ Bearings Light Preload |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
16 |
| Radial Static Load Rating C0r (N) |
16100 |
| Radial Dynamic Load Rating Cr (N) |
29000 |
| Basic static load rating, radial (C 0r) |
"16100.0000" |
| Limiting speed for grease lubrication (n G Grease) |
18000 |
| Limiting speed for oil lubrication (n G Oil) |
28000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
Suffix description
| C |
15° Or 17° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL |
Set Of 2 Universal Bearings, Light Preload |
