FAG 7603030-TVP-L055

FAG 7603030-TVP-L055
FAG 7603030-TVP-L055 rulman resim 1
FAG 7603030-TVP-L055 rulman resim 2
FAG 7603030-TVP-L055 rulman resim 3
Price: 180.14 $
Specifications
Brand FAG
Item Number 7603030-TVP-L055 FAG
Manufacturer Part Number 0387269120000
EAN 4026677577986
Category Angular Contact Thrust Ball Bearings, Single Direction
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 72
Width (B) MM 19
Inner (d) Inch 1.1811
Outer (D) Inch 2.8346
Width (B) Inch 0.748
Weight (kg) 0.409 kg
Product Properties
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Data from Schaeffler (medias)
Width (b) mm 19
Axial Static Load Rating C0a (N) 89000
Axial Dynamic Load Rating Ca (N) 36500
Limiting speed for grease lubrication (n G Grease) 5700
Thermally safe operating speed (n u03d1) 3200
ECLASS number 23-05-10-02
ECLASS2 number 23-05-10-02
Medias description Axial angular contact ball bearings 7603, single direction, with contact angle a = 60°, restricted tolerances
Suffix description
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
L055 Bearing Greased With High Performance Grease Arcanol MULTITOP
