FAG 7602020-2RS-TVP

FAG 7602020-2RS-TVP
FAG 7602020-2RS-TVP rulman resim 1
FAG 7602020-2RS-TVP rulman resim 2
FAG 7602020-2RS-TVP rulman resim 3
FAG 7602020-2RS-TVP rulman resim 4
Price: 168.54 $
Specifications
Brand FAG
Item Number 7602020-2RS-TVP FAG
Manufacturer Part Number 0386553730000
EAN 4026677849489
Category Angular Contact Thrust Ball Bearings, Single Direction
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 47
Width (B) MM 14
Inner (d) Inch 0.7874
Outer (D) Inch 1.8504
Width (B) Inch 0.5512
Weight (kg) 0.12 kg
Product Properties
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Data from Schaeffler (medias)
Width (b) mm 14
Axial Static Load Rating C0a (N) 38000
Axial Dynamic Load Rating Ca (N) 19100
Limiting speed for grease lubrication (n G Grease) 6800
Thermally safe operating speed (n u03d1) 5000
ECLASS number 23-05-10-02
ECLASS2 number 23-05-10-02
Medias description Axial angular contact ball bearings 7602..-2RS, single direction, with contact angle a = 60°, restricted tolerances, lip seals on both sides
Suffix description
2RS Rubber Seals At Each Side Of The Bearing
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
