FAG 7338-B-MP-UA Image 2
Visual product photo and picture of the product.
Price: 4,528.28 $
Specifications
Weight and Dimensions
| Inner (d) MM |
190 |
| Outer (D) MM |
400 |
| Width (B) MM |
78 |
| Inner (d) Inch |
7.4803 |
| Outer (D) Inch |
15.748 |
| Width (B) Inch |
3.0709 |
| Weight (kg) |
48 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Precision |
Standard Precision |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
78 |
| Radial Static Load Rating C0r (N) |
630000 |
| Radial Dynamic Load Rating Cr (N) |
440000 |
| Basic static load rating, radial (C 0r) |
"630000.0000" |
| Limiting speed (n G) |
2490 |
| Reference speed (n u03d1r) |
1680 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 73..-B-MP, single row |
Suffix description
| B |
40° Contact Angle |
| MP |
Machined Brass Cage, Window Type, Rolling Element Riding |
| UA |
Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
