FAG 7315-B-XL-MP-UA80 Image 2
Visual product photo and picture of the product.
Price: 415.72 $
Specifications
Weight and Dimensions
| Inner (d) MM |
75 |
| Outer (D) MM |
160 |
| Width (B) MM |
37 |
| Inner (d) Inch |
2.9528 |
| Outer (D) Inch |
6.2992 |
| Width (B) Inch |
1.4567 |
| Weight (kg) |
3.51 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Precision |
Standard Precision |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
U8 - Small Axial Clearance (80) |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
37 |
| Radial Static Load Rating C0r (N) |
107000 |
| Radial Dynamic Load Rating Cr (N) |
140000 |
| Limiting speed (n G) |
7300 |
| Reference speed (n u03d1r) |
4500 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 73..-B-XL-MP, single row |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| MP |
Machined Brass Cage, Window Type, Rolling Element Riding |
| UA |
Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
| UA80 |
Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance, 80u03bcm |
