FAG 7312-B-XL-MP-P5-UO

FAG 7312-B-XL-MP-P5-UO
FAG 7312-B-XL-MP-P5-UO rulman resim 1
FAG 7312-B-XL-MP-P5-UO rulman resim 2
FAG 7312-B-XL-MP-P5-UO rulman resim 3
FAG 7312-B-XL-MP-P5-UO rulman resim 4
Price: 401.58 $
Specifications
Brand FAG
Item Number 7312-B-XL-MP-P5-UO FAG
Manufacturer Part Number 0384773510000
Also known as 7312-B-MP-P5-UO
EAN 4026677282156
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 130
Width (B) MM 31
Inner (d) Inch 2.3622
Outer (D) Inch 5.1181
Width (B) Inch 1.2205
Weight (kg) 1.92 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision P5 Precision (Higher than P6)
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 31
Radial Static Load Rating C0r (N) 69000
Radial Dynamic Load Rating Cr (N) 96000
Basic static load rating, radial (C 0r) "69000.0000"
Limiting speed (n G) 9200
Reference speed (n u03d1r) 5300
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 73..-B-XL-MP, single row
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
