FAG 7310-B-XL-TVP-UA80

FAG 7310-B-XL-TVP-UA80
FAG 7310-B-XL-TVP-UA80 rulman resim 1
FAG 7310-B-XL-TVP-UA80 rulman resim 2
FAG 7310-B-XL-TVP-UA80 rulman resim 3
FAG 7310-B-XL-TVP-UA80 rulman resim 4
Price: 109.18 $
Specifications
Brand FAG
Item Number 7310-B-XL-TVP-UA80 FAG
Manufacturer Part Number 0384063650000
Also known as 7310-B-TVP-UA80
EAN 4026677172846
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 110
Width (B) MM 27
Inner (d) Inch 1.9685
Outer (D) Inch 4.3307
Width (B) Inch 1.063
Weight (kg) 1.215 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload U8 - Small Axial Clearance (80)
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 27
Radial Static Load Rating C0r (N) 50000
Radial Dynamic Load Rating Cr (N) 75000
Basic static load rating, radial (C 0r) "50000.0000"
Limiting speed (n G) 8400
Reference speed (n u03d1r) 6100
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 73..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding,
UA80 Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance, 80u03bcm
