FAG 7310-B-XL-TVP-P5-UO

FAG 7310-B-XL-TVP-P5-UO
FAG 7310-B-XL-TVP-P5-UO rulman resim 1
FAG 7310-B-XL-TVP-P5-UO rulman resim 2
FAG 7310-B-XL-TVP-P5-UO rulman resim 3
Price: 175.29 $
Specifications
Brand FAG
Item Number 7310-B-XL-TVP-P5-UO FAG
Manufacturer Part Number 0191174420000
Also known as 7310-B-TVP-P5-UO
EAN 4012801166584
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 110
Width (B) MM 27
Inner (d) Inch 1.9685
Outer (D) Inch 4.3307
Width (B) Inch 1.063
Weight (kg) 1.05 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision P5 Precision (Higher than P6)
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 27
Radial Static Load Rating C0r (N) 50000
Radial Dynamic Load Rating Cr (N) 75000
Basic static load rating, radial (C 0r) "50000.0000"
Limiting speed (n G) 8400
Reference speed (n u03d1r) 6100
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 73..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
