FAG 7309-B-XL-JP-UA Image 2
Visual product photo and picture of the product.
Price: 72.57 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
100 |
| Width (B) MM |
25 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
3.937 |
| Width (B) Inch |
0.9843 |
| Weight (kg) |
0.9 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Precision |
Standard Precision |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
25 |
| Radial Static Load Rating C0r (N) |
43000 |
| Radial Dynamic Load Rating Cr (N) |
65000 |
| Basic static load rating, radial (C 0r) |
"43000.0000" |
| Limiting speed (n G) |
9300 |
| Reference speed (n u03d1r) |
6500 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 73..-B-XL-JP, single row |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| JP |
Pressed Steel Cage, Rolling Element Guided |
| UA |
Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
