FAG 7305-B-XL-TVP-P5

FAG 7305-B-XL-TVP-P5
FAG 7305-B-XL-TVP-P5 rulman resim 1
FAG 7305-B-XL-TVP-P5 rulman resim 2
FAG 7305-B-XL-TVP-P5 rulman resim 3
FAG 7305-B-XL-TVP-P5 rulman resim 4
Price: 74.66 $
Specifications
Brand FAG
Item Number 7305-B-XL-TVP-P5 FAG
Manufacturer Part Number 0191168610000
EAN 4012801327336
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 62
Width (B) MM 17
Inner (d) Inch 0.9843
Outer (D) Inch 2.4409
Width (B) Inch 0.6693
Weight (kg) 0.23 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision P5 Precision (Higher than P6)
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 15800
Radial Dynamic Load Rating Cr (N) 28000
Basic static load rating, radial (C 0r) "15800.0000"
Limiting speed (n G) 15800
Reference speed (n u03d1r) 9800
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 73..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
