FAG 7303-B-XL-TVP-P5-UL Image 3
Visual product photo and picture of the product.
Price: 66.00 $
Specifications
Weight and Dimensions
| Inner (d) MM |
17 |
| Outer (D) MM |
47 |
| Width (B) MM |
16 |
| Inner (d) Inch |
0.6693 |
| Outer (D) Inch |
1.8504 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.113 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| Precision |
P5 Precision (Higher than P6) |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
14 |
| Radial Static Load Rating C0r (N) |
9000 |
| Radial Dynamic Load Rating Cr (N) |
17600 |
| Basic static load rating, radial (C 0r) |
"9000.0000" |
| Limiting speed (n G) |
21600 |
| Reference speed (n u03d1r) |
12800 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 73..-B-XL-TVP, single row |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| TVP |
Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| P5 |
Dimensional And Running Accuracy To ISO Tolerance Class 5 |
| UL |
Single Bearing, Universal, Light Preload |
