FAG 7226-B-XL-MP Image 4
Visual product photo and picture of the product.
Price: 512.51 $
Specifications
Weight and Dimensions
| Inner (d) MM |
130 |
| Outer (D) MM |
230 |
| Width (B) MM |
40 |
| Inner (d) Inch |
5.1181 |
| Outer (D) Inch |
9.0551 |
| Width (B) Inch |
1.5748 |
| Weight (kg) |
6.92 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Precision |
Standard Precision |
| Contact Angle |
40 degrees |
| Pairing |
No pairing |
| Axial Internal Clearance / Preload |
No Preload |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
40 |
| Radial Static Load Rating C0r (N) |
204000 |
| Radial Dynamic Load Rating Cr (N) |
200000 |
| Basic static load rating, radial (C 0r) |
"204000.0000" |
| Limiting speed (n G) |
4850 |
| Reference speed (n u03d1r) |
3350 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| MP |
Machined Brass Cage, Window Type, Rolling Element Riding |
