FAG 7224-B-XL-MP-P5-UO Image 4
Visual product photo and picture of the product.
Price: 1,154.04 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
215 |
| Width (B) MM |
40 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
8.4646 |
| Width (B) Inch |
1.5748 |
| Weight (kg) |
6.08 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Precision |
P5 Precision (Higher than P6) |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UO - Zero Clearance |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
40 |
| Radial Static Load Rating C0r (N) |
178000 |
| Radial Dynamic Load Rating Cr (N) |
182000 |
| Basic static load rating, radial (C 0r) |
"178000.0000" |
| Limiting speed (n G) |
5200 |
| Reference speed (n u03d1r) |
3700 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| MP |
Machined Brass Cage, Window Type, Rolling Element Riding |
| P5 |
Dimensional And Running Accuracy To ISO Tolerance Class 5 |
| UO |
Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance |
