FAG 7217-B-XL-TVP-P5-UO Image 3
Visual product photo and picture of the product.
Price: 406.36 $
Specifications
Weight and Dimensions
| Inner (d) MM |
85 |
| Outer (D) MM |
150 |
| Width (B) MM |
28 |
| Inner (d) Inch |
3.3465 |
| Outer (D) Inch |
5.9055 |
| Width (B) Inch |
1.1024 |
| Weight (kg) |
1.81 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| Precision |
P5 Precision (Higher than P6) |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UO - Zero Clearance |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
28 |
| Radial Static Load Rating C0r (N) |
86000 |
| Radial Dynamic Load Rating Cr (N) |
97000 |
| Basic static load rating, radial (C 0r) |
"86000.0000" |
| Limiting speed (n G) |
5900 |
| Reference speed (n u03d1r) |
4750 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 72..-B-XL-TVP, single row |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| TVP |
Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| P5 |
Dimensional And Running Accuracy To ISO Tolerance Class 5 |
| UO |
Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance |
