FAG 7213-B-XL-TVP-UA

FAG 7213-B-XL-TVP-UA
FAG 7213-B-XL-TVP-UA rulman resim 1
FAG 7213-B-XL-TVP-UA rulman resim 2
FAG 7213-B-XL-TVP-UA rulman resim 3
FAG 7213-B-XL-TVP-UA rulman resim 4
Price: 75.94 $
Specifications
Brand FAG
Item Number 7213-B-XL-TVP-UA FAG
Manufacturer Part Number 0167253870000
Also known as 7213-B-TVP-UA
EAN 4012801166195
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 65
Outer (D) MM 120
Width (B) MM 23
Inner (d) Inch 2.5591
Outer (D) Inch 4.7244
Width (B) Inch 0.9055
Weight (kg) 1.03 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 55000
Radial Dynamic Load Rating Cr (N) 71000
Basic static load rating, radial (C 0r) "55000.0000"
Limiting speed (n G) 7600
Reference speed (n u03d1r) 5700
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 72..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
UA Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance
