FAG 7213-B-XL-MP

FAG 7213-B-XL-MP
FAG 7213-B-XL-MP rulman resim 1
FAG 7213-B-XL-MP rulman resim 2
FAG 7213-B-XL-MP rulman resim 3
FAG 7213-B-XL-MP rulman resim 4
Price: 126.54 $
Specifications
Brand FAG
Item Number 7213-B-XL-MP FAG
Manufacturer Part Number 0191153180000
Also known as 7213-B-MP
EAN 4012801282512
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 65
Outer (D) MM 120
Width (B) MM 23
Inner (d) Inch 2.5591
Outer (D) Inch 4.7244
Width (B) Inch 0.9055
Weight (kg) 1.098 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 52000
Radial Dynamic Load Rating Cr (N) 68000
Basic static load rating, radial (C 0r) "52000.0000"
Limiting speed (n G) 9900
Reference speed (n u03d1r) 5700
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
