FAG 7212-B-XL-MP-P5-UM Image 4
Visual product photo and picture of the product.
Price: 296.04 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
110 |
| Width (B) MM |
22 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
4.3307 |
| Width (B) Inch |
0.8661 |
| Weight (kg) |
0.87 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Precision |
P5 Precision (Higher than P6) |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
22 |
| Radial Static Load Rating C0r (N) |
45000 |
| Radial Dynamic Load Rating Cr (N) |
62000 |
| Basic static load rating, radial (C 0r) |
"45000.0000" |
| Limiting speed (n G) |
10800 |
| Reference speed (n u03d1r) |
6200 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| MP |
Machined Brass Cage, Window Type, Rolling Element Riding |
| P5 |
Dimensional And Running Accuracy To ISO Tolerance Class 5 |
| UM |
Single Bearing, Universal, Medium Preload |
