FAG 7209-B-XL-TVP

FAG 7209-B-XL-TVP
FAG 7209-B-XL-TVP rulman resim 1
FAG 7209-B-XL-TVP rulman resim 2
FAG 7209-B-XL-TVP rulman resim 3
FAG 7209-B-XL-TVP rulman resim 4
Price: 32.67 $
Specifications
Brand FAG
Item Number 7209-B-XL-TVP FAG
Manufacturer Part Number 0167252120000
Also known as 7209-B-TVP
EAN 4012801166065
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.42 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 27000
Radial Dynamic Load Rating Cr (N) 40000
Basic static load rating, radial (C 0r) "27000.0000"
Limiting speed (n G) 11000
Reference speed (n u03d1r) 8000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 72..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
