FAG 7209-B-XL-MP-P6-UA

FAG 7209-B-XL-MP-P6-UA
FAG 7209-B-XL-MP-P6-UA rulman resim 1
FAG 7209-B-XL-MP-P6-UA rulman resim 2
FAG 7209-B-XL-MP-P6-UA rulman resim 3
FAG 7209-B-XL-MP-P6-UA rulman resim 4
Price: 94.89 $
Specifications
Brand FAG
Item Number 7209-B-XL-MP-P6-UA FAG
Also known as 7209-B-MP-P6-UA
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.43 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision P6 Precision (Higher than Standard)
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Radial Static Load Rating C0r (N) 27000
Radial Dynamic Load Rating Cr (N) 40000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
P6 Dimensional And Running Accuracy To ISO Tolerance Class 6 (Better Than Normal)
UA Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance
