FAG 7209-B-XL-JP-UA

FAG 7209-B-XL-JP-UA
FAG 7209-B-XL-JP-UA rulman resim 1
FAG 7209-B-XL-JP-UA rulman resim 2
FAG 7209-B-XL-JP-UA rulman resim 3
FAG 7209-B-XL-JP-UA rulman resim 4
Price: 60.21 $
Specifications
Brand FAG
Item Number 7209-B-XL-JP-UA FAG
Manufacturer Part Number 0191148850000
Also known as 7209-B-JP-UA
EAN 4012801326803
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.414 kg
Product Properties
Seal No Seal
Cage Type S - Steel or Standard Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 27000
Radial Dynamic Load Rating Cr (N) 40000
Basic static load rating, radial (C 0r) "27000.0000"
Limiting speed (n G) 11000
Reference speed (n u03d1r) 8000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
JP Pressed Steel Cage, Rolling Element Guided
UA Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance
