FAG 7208-B-XL-JP

FAG 7208-B-XL-JP
FAG 7208-B-XL-JP rulman resim 1
FAG 7208-B-XL-JP rulman resim 2
FAG 7208-B-XL-JP rulman resim 3
Price: 34.14 $
Specifications
Brand FAG
Item Number 7208-B-XL-JP FAG
Manufacturer Part Number 0191147960000
Also known as 7208-B-JP
EAN 4026677046253
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 80
Width (B) MM 18
Inner (d) Inch 1.5748
Outer (D) Inch 3.1496
Width (B) Inch 0.7087
Weight (kg) 0.356 kg
Product Properties
Seal No Seal
Cage Type S - Steel or Standard Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 18
Radial Static Load Rating C0r (N) 23500
Radial Dynamic Load Rating Cr (N) 36000
Basic static load rating, radial (C 0r) "23500.0000"
Limiting speed (n G) 11900
Reference speed (n u03d1r) 8600
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
JP Pressed Steel Cage, Rolling Element Guided
