FAG 7207-B-XL-JP

FAG 7207-B-XL-JP
FAG 7207-B-XL-JP rulman resim 1
FAG 7207-B-XL-JP rulman resim 2
FAG 7207-B-XL-JP rulman resim 3
FAG 7207-B-XL-JP rulman resim 4
Price: 33.21 $
Specifications
Brand FAG
Item Number 7207-B-XL-JP FAG
Manufacturer Part Number 0191146800000
Also known as 7207-B-JP
EAN 4026677046239
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 72
Width (B) MM 17
Inner (d) Inch 1.378
Outer (D) Inch 2.8346
Width (B) Inch 0.6693
Weight (kg) 0.2716 kg
Product Properties
Seal No Seal
Cage Type S - Steel or Standard Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 19000
Radial Dynamic Load Rating Cr (N) 28000
Basic static load rating, radial (C 0r) "19000.0000"
Limiting speed (n G) 13400
Reference speed (n u03d1r) 9600
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
JP Pressed Steel Cage, Rolling Element Guided
