FAG 7205-B-XL-TVP-P6-UA

FAG 7205-B-XL-TVP-P6-UA
FAG 7205-B-XL-TVP-P6-UA rulman resim 1
FAG 7205-B-XL-TVP-P6-UA rulman resim 2
FAG 7205-B-XL-TVP-P6-UA rulman resim 3
FAG 7205-B-XL-TVP-P6-UA rulman resim 4
Price: 41.47 $
Specifications
Brand FAG
Item Number 7205-B-XL-TVP-P6-UA FAG
Also known as 7205-B-TVP-P6-UA
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.9843
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.131 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision P6 Precision (Higher than Standard)
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Radial Static Load Rating C0r (N) 9000
Radial Dynamic Load Rating Cr (N) 16200
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 72..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
P6 Dimensional And Running Accuracy To ISO Tolerance Class 6 (Better Than Normal)
UA Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance
