FAG 6205-C-HRS-C3

FAG 6205-C-HRS-C3
FAG 6205-C-HRS-C3 rulman resim 1
FAG 6205-C-HRS-C3 rulman resim 2
FAG 6205-C-HRS-C3 rulman resim 3
FAG 6205-C-HRS-C3 rulman resim 4
Price: 5.57 $
Specifications
Brand FAG
Item Number 6205-C-HRS-C3 FAG
Manufacturer Part Number 0622002400030
Also known as 6205-HRS-C3
EAN 4064327026675
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.9843
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.13 kg
Product Properties
Bore C - Cylindrical Bore
Seal RH - High Speed Low Friction Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 15
Radial Static Load Rating C0r (N) 7800
Radial Dynamic Load Rating Cr (N) 15900
Basic static load rating, radial (C 0r) "7800.0000"
Limiting speed (n G) 12200
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-C-HRS, single row, cf. DIN 625-1
Suffix description
C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
HRS High Speed/Low Friction Seal
C3 Internal Clearance Larger Than Normal
