FAG 7204-B-XL-JP

FAG 7204-B-XL-JP
FAG 7204-B-XL-JP rulman resim 1
FAG 7204-B-XL-JP rulman resim 2
FAG 7204-B-XL-JP rulman resim 3
FAG 7204-B-XL-JP rulman resim 4
FAG 7204-B-XL-JP rulman resim 5
FAG 7204-B-XL-JP rulman resim 6
Price: 18.54 $
Specifications
Brand FAG
Item Number 7204-B-XL-JP FAG
Manufacturer Part Number 0167250000000
Also known as 7204-B-JP
EAN 4026677046192
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 47
Width (B) MM 14
Inner (d) Inch 0.7874
Outer (D) Inch 1.8504
Width (B) Inch 0.5512
Weight (kg) 0.102 kg
Product Properties
Seal No Seal
Cage Type S - Steel or Standard Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 14
Radial Static Load Rating C0r (N) 7800
Radial Dynamic Load Rating Cr (N) 14900
Basic static load rating, radial (C 0r) "7800.0000"
Limiting speed (n G) 21600
Reference speed (n u03d1r) 15400
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
JP Pressed Steel Cage, Rolling Element Guided
