FAG 7204-B-XL-2RS-TVP

FAG 7204-B-XL-2RS-TVP
FAG 7204-B-XL-2RS-TVP rulman resim 1
FAG 7204-B-XL-2RS-TVP rulman resim 2
FAG 7204-B-XL-2RS-TVP rulman resim 3
FAG 7204-B-XL-2RS-TVP rulman resim 4
Price: 66.98 $
Specifications
Brand FAG
Item Number 7204-B-XL-2RS-TVP FAG
Manufacturer Part Number 0206765650000
Also known as 7204-B-2RS-TVP
EAN 4026677955722
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 47
Width (B) MM 14
Inner (d) Inch 0.7874
Outer (D) Inch 1.8504
Width (B) Inch 0.5512
Weight (kg) 0.111 kg
Product Properties
Seal 2RS - Rubber Seal on Two Sides
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 14
Radial Static Load Rating C0r (N) 7800
Radial Dynamic Load Rating Cr (N) 14900
Basic static load rating, radial (C 0r) "7800.0000"
Limiting speed (n G) 9500
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B-2RS, main dimensions to DIN 628-1, contact angle a = 40°, lip seals on both sides
Suffix description
B 40° Contact Angle
XL X-Life
2RS Rubber Seals At Each Side Of The Bearing
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
