FAG 7203-B-XL-TVP-UL Image 2
Visual product photo and picture of the product.
Price: 29.45 $
Specifications
Weight and Dimensions
| Inner (d) MM |
17 |
| Outer (D) MM |
40 |
| Width (B) MM |
12 |
| Inner (d) Inch |
0.6693 |
| Outer (D) Inch |
1.5748 |
| Width (B) Inch |
0.4724 |
| Weight (kg) |
0.07 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| Precision |
Standard Precision |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
12 |
| Radial Static Load Rating C0r (N) |
5700 |
| Radial Dynamic Load Rating Cr (N) |
11200 |
| Basic static load rating, radial (C 0r) |
"5700.0000" |
| Limiting speed (n G) |
26000 |
| Reference speed (n u03d1r) |
17100 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 72..-B-XL-TVP, single row |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| TVP |
Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| UL |
Single Bearing, Universal, Light Preload |
