FAG 6326-M-J20AA-C3 Image 2
Visual product photo and picture of the product.
Price: 1,531.12 $
Specifications
Weight and Dimensions
| Inner (d) MM |
130 |
| Outer (D) MM |
280 |
| Width (B) MM |
58 |
| Inner (d) Inch |
5.1181 |
| Outer (D) Inch |
11.0236 |
| Width (B) Inch |
2.2835 |
| Weight (kg) |
17.4 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Breakdown Voltage 1000v |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
58 |
| Radial Static Load Rating C0r (N) |
214000 |
| Radial Dynamic Load Rating Cr (N) |
244000 |
| Basic static load rating, radial (C 0r) |
"214000.0000" |
| Limiting speed (n G) |
4150 |
| Reference speed (n u03d1r) |
3500 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 63..-M-J20AA, single row, cf. DIN 625-1 |
Suffix description
| M |
Solid Brass Cage, Ball-Guided |
| J20AA |
Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments |
| C3 |
Internal Clearance Larger Than Normal |
