FAG 6313-C-2HRS-L237-C3 Image 3
Visual product photo and picture of the product.
Price: 124.26 $
Specifications
Weight and Dimensions
| Inner (d) MM |
65 |
| Outer (D) MM |
140 |
| Width (B) MM |
33 |
| Inner (d) Inch |
2.5591 |
| Outer (D) Inch |
5.5118 |
| Width (B) Inch |
1.2992 |
| Weight (kg) |
2.1 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2RH - High Speed Low Friction Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
2 - High Temperature Grease |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
33 |
| Radial Static Load Rating C0r (N) |
60000 |
| Radial Dynamic Load Rating Cr (N) |
101000 |
| Limiting speed (n G) |
4500 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 63..-C-2HRS, single row, cf. DIN 625-1 |
Suffix description
| C |
Deep Groove Ball Bearings Of Generation C, Modified Internal Construction |
| 2HRS |
Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal |
| L237 |
High Temperature Grease |
| C3 |
Internal Clearance Larger Than Normal |
