FAG 6312-M-P5-C2 Image 2
Visual product photo and picture of the product.
Price: 228.56 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
130 |
| Width (B) MM |
31 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
5.1181 |
| Width (B) Inch |
1.2205 |
| Weight (kg) |
2.09 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C2 Internal Play (Less than Cn) |
| Precision |
P5 Precision (Higher than P6) |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
31 |
| Radial Static Load Rating C0r (N) |
52000 |
| Radial Dynamic Load Rating Cr (N) |
89000 |
| Limiting speed (n G) |
10300 |
| Reference speed (n u03d1r) |
6700 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 63..-M, single row, cf. DIN 625-1 |
Suffix description
| M |
Solid Brass Cage, Ball-Guided |
| P5 |
Dimensional And Running Accuracy To ISO Tolerance Class 5 |
| C2 |
Bearing Internal Clearance Smaller Than Normal |
