FAG 6307-Z-C3 Image 5
Visual product photo and picture of the product.
Price: 15.20 $
Specifications
Weight and Dimensions
| Inner (d) MM |
35 |
| Outer (D) MM |
80 |
| Width (B) MM |
21 |
| Inner (d) Inch |
1.378 |
| Outer (D) Inch |
3.1496 |
| Width (B) Inch |
0.8268 |
| Weight (kg) |
0.461 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
Z - Steel Seal on One Side |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
21 |
| Basic static load rating, radial (C 0r) |
19100 |
| Limiting speed (n G) |
12300 |
| Reference speed (n u03d1r) |
9900 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
Suffix description
| Z |
Shield Of Pressed Sheet Steel On One Side Of The Bearing |
| C3 |
Internal Clearance Larger Than Normal |
