FAG 6236-MA-C4 Image 3
Visual product photo and picture of the product.
Price: 975.39 $
Specifications
Weight and Dimensions
| Inner (d) MM |
180 |
| Outer (D) MM |
320 |
| Width (B) MM |
52 |
| Inner (d) Inch |
7.0866 |
| Outer (D) Inch |
12.5984 |
| Width (B) Inch |
2.0472 |
| Weight (kg) |
18.2 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
52 |
| Radial Static Load Rating C0r (N) |
244000 |
| Radial Dynamic Load Rating Cr (N) |
240000 |
| Basic static load rating, radial (C 0r) |
"244000.0000" |
| Limiting speed (n G) |
3650 |
| Reference speed (n u03d1r) |
2750 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 62..-MA, single row, cf. DIN 625-1 |
Suffix description
| MA |
Machined Brass Cage, Outer Ring Guided |
| C4 |
Bearing Internal Clearance Greater Than C3 |
