FAG 6222-MA-F59-C3 Image 2
Visual product photo and picture of the product.
Price: 570.04 $
Specifications
Weight and Dimensions
| Inner (d) MM |
110 |
| Outer (D) MM |
200 |
| Width (B) MM |
38 |
| Inner (d) Inch |
4.3307 |
| Outer (D) Inch |
7.874 |
| Width (B) Inch |
1.4961 |
| Weight (kg) |
5.32 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
A2 - Reduced Width Tolerance |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
38 |
| Radial Static Load Rating C0r (N) |
117000 |
| Radial Dynamic Load Rating Cr (N) |
153000 |
| Basic static load rating, radial (C 0r) |
"117000.0000" |
| Limiting speed (n G) |
5800 |
| Reference speed (n u03d1r) |
4500 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 62..-MA, single row, cf. DIN 625-1 |
Suffix description
| MA |
Machined Brass Cage, Outer Ring Guided |
| F59 |
Replaced By |
| H68 |
Bearing And Bearing Parts For Voith Getriebe KG, Heidenheim; For Special Cage Design, Width Tolerance, Radial Runout And Bearing Clearance See Specifications |
| C3 |
Internal Clearance Larger Than Normal |
