FAG 6221-M-J20AA-C4 Image 3
Visual product photo and picture of the product.
Price: 968.43 $
Specifications
Weight and Dimensions
| Inner (d) MM |
105 |
| Outer (D) MM |
190 |
| Width (B) MM |
36 |
| Inner (d) Inch |
4.1339 |
| Outer (D) Inch |
7.4803 |
| Width (B) Inch |
1.4173 |
| Weight (kg) |
3.86 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Breakdown Voltage 1000v |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
36 |
| Basic static load rating, radial (C 0r) |
105000 |
| Limiting speed (n G) |
6100 |
| Reference speed (n u03d1r) |
4650 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
Suffix description
| M |
Solid Brass Cage, Ball-Guided |
| J20AA |
Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments |
| C4 |
Bearing Internal Clearance Greater Than C3 |
