FAG 6214-Z-S2-C3 Image 2
Visual product photo and picture of the product.
Price: 54.99 $
Specifications
Weight and Dimensions
| Inner (d) MM |
70 |
| Outer (D) MM |
125 |
| Width (B) MM |
24 |
| Weight (kg) |
1.08 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
Z - Steel Seal on One Side |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
S2 - Temperatures up to 250 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
24 |
| Radial Static Load Rating C0r (N) |
44000 |
| Radial Dynamic Load Rating Cr (N) |
66000 |
| Basic static load rating, radial (C 0r) |
"40000.0000" |
| Limiting speed (n G) |
8200 |
| Reference speed (n u03d1r) |
6200 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 62..-Z, single row, cf. DIN 625-1 |
Suffix description
| Z |
Shield Of Pressed Sheet Steel On One Side Of The Bearing |
| S2 |
Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +250°C (482°F) |
| C3 |
Internal Clearance Larger Than Normal |
