FAG 6214-J20AB-C3 Image 3
Visual product photo and picture of the product.
Price: 317.64 $
Specifications
Weight and Dimensions
| Inner (d) MM |
70 |
| Outer (D) MM |
125 |
| Width (B) MM |
24 |
| Inner (d) Inch |
2.7559 |
| Outer (D) Inch |
4.9213 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
1.07 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
J20AB |
Data from Schaeffler (medias)
| Width (b) mm |
24 |
| Radial Static Load Rating C0r (N) |
44000 |
| Radial Dynamic Load Rating Cr (N) |
66000 |
| Basic static load rating, radial (C 0r) |
"44000.0000" |
| Limiting speed (n G) |
8200 |
| Reference speed (n u03d1r) |
6100 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 62..-J20AB, single row, cf. DIN 625-1 |
Suffix description
| J20AB |
Puncture Voltage: 1.000vDC - Operating Environment: Dry, Damp - Layer Thickness: 100u03bcm - Possible Dimensions: 70mmu20131400mm Outside Diameter |
| C3 |
Internal Clearance Larger Than Normal |
