FAG 6211-C-Z-C3 Image 2
Visual product photo and picture of the product.
Price: 18.61 $
Specifications
Weight and Dimensions
| Inner (d) MM |
55 |
| Outer (D) MM |
100 |
| Width (B) MM |
21 |
| Inner (d) Inch |
2.1654 |
| Outer (D) Inch |
3.937 |
| Width (B) Inch |
0.8268 |
| Weight (kg) |
0.595 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
Z - Steel Seal on One Side |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
21 |
| Radial Static Load Rating C0r (N) |
29000 |
| Radial Dynamic Load Rating Cr (N) |
46500 |
| Basic static load rating, radial (C 0r) |
"29000.0000" |
| Limiting speed (n G) |
10400 |
| Reference speed (n u03d1r) |
8300 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 62..-C-Z, single row, cf. DIN 625-1 |
Suffix description
| C |
Deep Groove Ball Bearings Of Generation C, Modified Internal Construction |
| Z |
Shield Of Pressed Sheet Steel On One Side Of The Bearing |
| C3 |
Internal Clearance Larger Than Normal |
