FAG 6209-H-2Z-C3

FAG 6209-H-2Z-C3
FAG 6209-H-2Z-C3 rulman resim 1
FAG 6209-H-2Z-C3 rulman resim 2
FAG 6209-H-2Z-C3 rulman resim 3
FAG 6209-H-2Z-C3 rulman resim 4
Price: 9.64 $
Specifications
Brand FAG
Item Number 6209-H-2Z-C3 FAG
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.413 kg
Product Properties
Bore C - Cylindrical Bore
Seal ZZ/2Z - Steel Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 19190
Radial Dynamic Load Rating Cr (N) 29360
Basic static load rating, radial (C 0r) "19190.0000"
Limiting speed (n G) 9800
Reference speed (n u03d1r) 8800
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearings 62..-H-2Z, main dimensions to DIN 625-1, gap seals on both sides
Suffix description
H Basic Quality
2Z Two Metallic Shields
C3 Internal Clearance Larger Than Normal
