FAG 6206-C-2HRS-L069-CM Image 2
Visual product photo and picture of the product.
Price: 7.20 $
Specifications
Weight and Dimensions
| Inner (d) MM |
30 |
| Outer (D) MM |
62 |
| Width (B) MM |
16 |
| Inner (d) Inch |
1.1811 |
| Outer (D) Inch |
2.4409 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.192 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2RH - High Speed Low Friction Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Higher and Lower Temperature Grease |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Radial Static Load Rating C0r (N) |
11300 |
| Radial Dynamic Load Rating Cr (N) |
20800 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 62..-C-2HRS, single row, cf. DIN 625-1 |
Suffix description
| C |
Deep Groove Ball Bearings Of Generation C, Modified Internal Construction |
| 2HRS |
Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal |
| L069 |
Insert Bearing Grease For Wide Temperature Range - Polycarbamide Ester Oil - u201340°C to +180°C |
| CM |
|
