FAG 61976-MA Image 3
Visual product photo and picture of the product.
Price: 3,952.20 $
Specifications
Weight and Dimensions
| Inner (d) MM |
380 |
| Outer (D) MM |
520 |
| Width (B) MM |
65 |
| Inner (d) Inch |
14.9606 |
| Outer (D) Inch |
20.4724 |
| Width (B) Inch |
2.5591 |
| Weight (kg) |
40 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
65 |
| Radial Static Load Rating C0r (N) |
580000 |
| Radial Dynamic Load Rating Cr (N) |
365000 |
| Basic static load rating, radial (C 0r) |
"580000.0000" |
| Limiting speed (n G) |
2050 |
| Reference speed (n u03d1r) |
1450 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 619..-MA, single row, cf. DIN 625-1 |
Suffix description
| MA |
Machined Brass Cage, Outer Ring Guided |
